Network Switch vs Router vs Hub

This article will cover an in-depth comparison between network switch vs router vs hub. So, tech enthusiasts, this article is for you.

Network Switch vs Router vs Hub

We’re going to talk about a network switch vs router vs hub. Now, all three of these devices are similar, but there is a difference in the way they handle data. The fundamental difference between a hub and a switch is the way of delivery of frames. The router operates on the OSI model’s network layer. There can be Multiple connections of Ethernet Devices as a single segment by a hub. A switch can easily connect multiple devices inside a single LAN. Moreover, a router may connect both LAN and WAN networks.


Network Switch vs Router vs Hub- A Network Hub
A Network Hub

So, we’ll first talk about a hub. Let us first understand about hubs from network switch vs router vs hub. Now, the purpose of a hub is to connect all of your network devices together on an internal network. It’s a device that has multiple ports. It accepts Ethernet connections from network devices.

A hub is considered not to be intelligent because,

  • It does not filter any data or
  • Intelligent enough to know where to send the data.

The only thing a hub knows is when there is a connection of a device to one of its ports. So when there is an arrival of data packets at one of the ports, it is copied to all of the other ports.

As a result, all the devices on that hub detect that data packet.

Again, a data packet comes into one port. Then the hub will just rebroadcast that data to every port that has a connection of device to it.

Now, even if a computer only wants to communicate with a specific other computer, any other computer in the connection would still receive the data. Even though that data was not for them. As a result, this causes loss in bandwidth. Again, there are security concerns too. This creates network traffic that is not necessary.


Network Switch vs Router vs Hub - A Network Switch
A Network Switch

The basic mechanism of a switch is very similar to a hub. A switch is a device with many Ethernet ports just like a Hub.

The main difference between them is that unlike a hub, a switch is intelligent.

  1. A switch can actually learn the physical addresses of the devices.
  2. It learns the physical addresses of the devices that are in connection to it.
  3. It not only recognizes the addresses but also stores these physical addresses.
  4. These addresses are quite famous by the name MAC addresses.

In this case, unlike a hub the data packet only transfers to the computer connection the sender wants to. Whereas a hub will just rebroadcast the data to every port.

For example, a switch can easily transmit data to a computer that the sender wants to. Here, the switch looks through the MAC Addresses in its register and finds the ideal match. Then it sends the data to the correct recipient.

So that’s the major difference between a hub and a switch. As a result switches are far more preferable over hubs. Because they reduce any unnecessary traffic on the network. A hub can  only detect a device in physical connection to it. On the other hand, a switch can detect specific devices in its connection. Because it keeps a record of the MAC addresses of those devices.


Network Switch vs Router vs Hub- A Network Router
A Network Router

Hubs and switches exchange data within a local area network. For example, in your home network or in a business. They do not have any use to exchange data outside their own network, such as out on the internet. There is a reason for it. Here, to exchange or route data outside their own network to another network, such as out on the internet, a device needs to be able to read IP addresses. Again, hubs and switches do not read IP addresses. So that’s where the router comes in.

Read about What is Computer Networking

Now a router does exactly what its name implies.

  1. A router is a device that routes or forwards data from one network to another on the basis of their IP address.
  2. When a router receives a data packet, the router inspects the data’s IP address.
  3. It then determines if the packet was for its own network or if it’s meant for another network.
  4. If the router determines that the data packet is meant for its own network, it receives it.
  5. But if it’s not meant for its own network, it sends it off to another network. So a router is essentially the gateway of a network.

An Example

Suppose, we have a private network with a router. Let us assume it to be the ‘red network’ (Red in color). Again, there are different other data packets, by different colors like yellow, blue, green, etc. These colors indicate different IP addresses. Now, they will try to enter the red network’s router from the internet.

In this situation, the router will accept only the red data packets. Because the red ones are the only ones for this network. So, this router will reject all of the other data packets, the yellows, blues, greens, etc. Because they were not for this network. Again, their IP addresses were not meant for this network.

The Working Principle of a Router | How it reaches the Red Network from the Blue Network

Take the previous four colors for example, red, yellow, blue, green. Each network has their own router. Now let’s see how a router operates.

  1. At first, each network will start exchanging information within their own network.
  2. Their data will not go out on the internet.
  3. So they are not communicating with other networks.
  4. They are just exchanging data within their own network using their hub or switch.
  5. Now, let’s exchange data between different networks.
  6. Suppose you want to share data from the red network to the blue network.
  7. So, you want to communicate with a computer on another network.
  8. For this to happen, the data packet has to leave their own network and go out on the internet.
  9. As a result, the computer sends their data.
  10. The data reaches the network’s router
  11. Once the data packet reaches the router, the Router will look at the IP address of the data packet.
  12. It then forwards the data out on the internet to the next router
  13. As a result, it makes its way to the blue network’s router.
  14. In the end, it reaches the intended destination computer.

So in a nutshell this is how routers work. So in conclusion, hubs and switches are used to create networks while routers are used to connect networks. Now, among network switch vs router vs Hub, the best device that is in demand right now is the router. Its functionality is not very hard to grasp. Nowadays, in the age of Wireless Fidelity (WiFi), the use of routers is far more relevant than the hubs and switches. So, in terms of network switch vs router vs hub, router is the one that ranks in the top for network and connectivity works.


I hope you enjoyed my ultimate guide to network switch vs router vs hub.

Now I’d like to hear from you: do you use a router? Do you like the hub or the switch?

Either way, let me know by leaving a quick comment below.
